Features:
- Solid
Construction
- Compact Height
- Replaces Adapter
- Up to 5000 psi
- Integral Gate Valve
available
- Hydraulically-operated spring
return
- Up to 5" Rams
- Operating temperatures from
-50?to +650?F
|
 |
CROWN
Composite Pumping Tree
Models
|
| Type R
Basic manually operated design
available with patented rams for pressures up to 2000 psi,
steel reinforced rams for pressures up to 3000 psi, & low
pressure rams for pressures up to 1500 psi & sealing on
rods from 0 to 1?inches in diameter.
|
 |
 |
Type
B
Pressure-balanced design for
improved operations of rams with high production pressures up
to 3000 psi. |
Type C
Designed for high temperature
applications, this innovative design is easy to operate and
uses a unique combination of metallic and non-elastomeric
materials in the construction of the rams. This model
will withstand temperatures up to 650 F and pressure
conditions up to 3000 psi. |
 |
 |
Type
D
The oval shaped ram design used in
this model allows a further reduction in the overall
height. This is a pressure-balanced design for pressures
up to 3000 psi. |
| Type H
Hydraulically / manually operated
design is available with patented rams for pressures up to
2000 psi, steel reinforced rams for pressures up to 3000 psi,
and low pressure rams for pressures up to 1500 psi and sealing
on rods from 0 to 1?quot; in diameter. |
 |
